Galvanneal / Satin Coat
Explore our full range of galvanneal/satin coat steel sheets for your application.
Looking for industry-leading materials? Our galvanneal/ satin coat sheets are processed on our light gauge tension level line, providing some of the highest quality coated products in the industry. We focus on optimal flatness, squareness and surface finish.
Galvanneal / Satin Coat Specifications
| Gauge No. | Thickness Decimal Equivalent | Order Limits | Weight lbs./sq. ft. |
|---|---|---|---|
| 8 | 0.1681 | 0.1756-0.1607 | 7.031 |
| 9 | 0.1532 | 0.1606-0.1458 | 6.406 |
| 10 | 0.1382 | 0.1457-0.1308 | 5.781 |
| 11 | 0.1233 | 0.1307-0.1159 | 5.156 |
| 12 | 0.1084 | 0.1158-0.1009 | 4.531 |
| 13 | 0.0934 | 0.1008-0.086 | 3.906 |
| 14 | 0.0785 | 0.0859-0.0748 | 3.281 |
| 15 | 0.071 | 0.0747-0.0673 | 2.969 |
| 16 | 0.0635 | 0.0672-0.0806 | 2.656 |
| 17 | 0.0575 | 0.0605-0.0546 | 2.406 |
| 18 | 0.0516 | 0.0545-0.0486 | 2.156 |
| 19 | 0.0456 | 0.0485-0.0426 | 1.906 |
| 20 | 0.0396 | 0.0425-0.0382 | 1.656 |
| 21 | 0.0366 | 0.0381-0.0352 | 1.531 |
| 22 | 0.0336 | 0.0351-0.0322 | 1.406 |
| 23 | 0.0306 | 0.0321-0.0292 | 1.281 |
| 24 | 0.0276 | 0.0291-0.0262 | 1.156 |
| 25 | 0.0247 | 0.0261-0.0232 | 1.031 |
| 26 | 0.0217 | 0.0231-0.021 | 0.906 |
| 27 | 0.0202 | 0.0209-0.0195 | 0.844 |
| 28 | 0.0187 | 0.0194-0.018 | 0.781 |
| 29 | 0.0172 | 0.0179-0.0165 | 0.719 |
| 30 | 0.0157 | 0.0164-0.015 | 0.656 |
| 31 | 0.0142 | 0.0149-0.0138 | 0.594 |
