Galvanized - Del Metals

Explore our entire offering of galvanized steel.

We stock a full range of galvanized steel in various thicknesses. They are processed on our light gauge tension level line, to produce some of the highest quality coated products in the industry, with optimal flatness, squareness and surface finish. We stock a variety of gauges including g40, g60, and g90.

Galvanized Specifications

Gauge No.	Thickness Decimal Equivalent	Order Limits	Weight lbs./sq. ft.
8	0.1681	0.1756-0.1607	7.031
9	0.1532	0.1606-0.1458	6.406
10	0.1382	0.1457-0.1308	5.781
11	0.1233	0.1307-0.1159	5.156
12	0.1084	0.1158-0.1009	4.531
13	0.0934	0.1008-0.086	3.906
14	0.0785	0.0859-0.0748	3.281
15	0.071	0.0747-0.0673	2.969
16	0.0635	0.0672-0.0806	2.656
17	0.0575	0.0605-0.0546	2.406
18	0.0516	0.0545-0.0486	2.156
19	0.0456	0.0485-0.0426	1.906
20	0.0396	0.0425-0.0382	1.656
21	0.0366	0.0381-0.0352	1.531
22	0.0336	0.0351-0.0322	1.406
23	0.0306	0.0321-0.0292	1.281
24	0.0276	0.0291-0.0262	1.156
25	0.0247	0.0261-0.232	1.031
26	0.0217	0.0231-0.0221	0.906
27	0.0202	0.0209-0.0195	0.844
28	0.0187	0.0194-0.018	0.781
29	0.0172	0.0179-0.0165	0.719
30	0.0157	0.0164-0.015	0.656
31	0.0142	0.0149-0.0139	0.594
