Discover a Full Range of Structural Steel Angles for your project.
We offer equal and unequal angles for your project requirements. Angles are designed with an L-shaped cross-section which makes them stable and increases load-bearing capabilities. We store all of our angles in a temperature-controlled warehouse to ensure the quality of our materials for your project.
Equal Angles Specifications
| Size in Inches | Thickness t in. | Lbs. Per Ft. | |
|---|---|---|---|
| 1/2" | x 1/2" | 1/8" | 0.38 |
| 5/8" | x 5/8" | 1/8" | 0.48 |
| 3/4" | x 3/4" | 1/8" | 0.59 |
| x 3/4" | 3/16" | 0.84 | |
| 1" | x 1" | 1/8" | 0.8 |
| x 1" | 3/16" | 1.16 | |
| x 1" | 1/4" | 1.49 | |
| 1-1/4" | x 1-1/4" | 1/8" | 1.01 |
| x 1-1/4" | 3/16" | 1.48 | |
| x 1-1/4" | 1/4" | 1.92 | |
| 1-1/2" | x 1-1/2" | 1/8" | 1.23 |
| x 1-1/2" | 3/16" | 1.8 | |
| x 1-1/2" | 1/4" | 2.34 | |
| 1-3/4" | x 1-3/4" | 1/8" | 1.44 |
| x 1-1/4" | 3/16" | 1.8 | |
| x 1-3/4" | 3/16" | 2.12 | |
| x 1-3/4" | 1/4" | 2.77 | |
| 2" | x 2" | 1/8" | 1.65 |
| x 2" | 3/16" | 2.44 | |
| x 2" | 1/4" | 3.19 | |
| x 2" | 5/16" | 3.92 | |
| x 2" | 3/8" | 4.7 | |
| 2-1/2" | x 2-1/2" | 1/8" | 2.08 |
| x 2-1/2" | 3/16" | 3.07 | |
| x 2-1/2" | 1/4" | 4.1 | |
| x 2-1/2" | 5/16" | 5 | |
| x 2-1/2" | 3/8" | 5.9 | |
| x 2-1/2" | 1/2" | 7.7 | |
| 3" | x 3" | 3/16" | 3.7 |
| x 3" | 1/4" | 4.9 | |
| x 3" | 5/16" | 6.1 | |
| x 3" | 3/8" | 7.2 | |
| 3" | x 3" | 7/16" | 8.3 |
| 3" | x 3" | 1/2" | 9.4 |
| 3-1/2" | x 3-1/2" | 1/4" | 5.8 |
| x 3-1/2" | 5/16" | 7.2 | |
| x 3-1/2" | 3/8" | 8.5 | |
| x 3-1/2" | 1/2" | 11.1 | |
| 4" | x 4" | 1/4" | 6.6 |
| x 4" | 5/16" | 8.2 | |
| x 4" | 3/8" | 9.8 | |
| x 4" | 1/2" | 12.8 | |
| x 4" | 5/8" | 15.7 | |
| x 4" | 3/4" | 18.5 | |
| 5" | x 5" | 5/16" | 10.3 |
| x 5" | 3/8" | 12.3 | |
| x 5" | 1/2" | 16.2 | |
| x 5" | 5/8" | 20 | |
| 5" | x 5" | 3/4" | 23.6 |
| 6" | x 6" | 5/16" | 12.4 |
| x 6" | 3/8" | 14.9 | |
| x 6" | 1/2" | 19.6 | |
| x 6" | 9/16" | 21.9 | |
| x 6" | 5/8" | 24.2 | |
| x 6" | 3/4" | 28.7 | |
| x 6" | 1" | 37.4 | |
| 8" | x 8" | 1/2" | 26.4 |
| x 8" | 5/8" | 32.7 | |
| x 8" | 3/4" | 38.9 | |
| x 8" | 1" | 51 |
Unequal Angles Specifications
| Size in Inches | Thickness t in. | Lbs. Per Ft. | |
|---|---|---|---|
| 2" | 1-1/2" | 1/8" | 1.44 |
| 2" | 1-1/2" | 3/16" | 2.12 |
| 2" | 1-1/2" | 1/4" | 2.77 |
| 2-1/2" | 1-1/2" | 3/16" | 2.44 |
| 2-1/2" | 1-1/2" | 1/4" | 3.19 |
| 2-1/2" | 2" | 1/8" | 1.86 |
| 2-1/2" | 2" | 3/16" | 2.75 |
| 2-1/2" | 2" | 1/4" | 3.62 |
| 2-1/2" | 2" | 5/16" | 4.5 |
| 2-1/2" | 2" | 3/8" | 5.3 |
| 3" | 2" | 3/16" | 3.07 |
| 3" | 2" | 1/4" | 4.1 |
| 3" | 2" | 1/2" | 7.7 |
| 3" | 2" | 5/16" | 5 |
| 3" | 2" | 3/8" | 5.9 |
| 3" | 2" | 1/2" | 7.7 |
| 3" | 2-1/2" | 1/4" | 4.5 |
| 3" | 2-1/2" | 3/8" | 6.6 |
| 3-1/2" | 2-1/2" | 1/4" | 4.9 |
| 3-1/2" | 2-1/2" | 5/16" | 6.1 |
| 3-1/2" | 2-1/2" | 3/8" | 7.2 |
| 3-1/2" | 2-1/2" | 1/2" | 9.4 |
| 3-1/2" | 3" | 1/4" | 5.4 |
| 3-1/2" | 3" | 5/16" | 6.6 |
| 3-1/2" | 3" | 3/8" | 7.9 |
| 3-1/2" | 3" | 1/2" | 10.2 |
| 4" | 3" | 1/4" | 5.8 |
| 4" | 3" | 5/16" | 7.2 |
| 4" | 3" | 3/8" | 8.5 |
| 4" | 3" | 1/2" | 11.1 |
| 4" | 3-1/2" | 1/4" | 6.2 |
| 4" | 3-1/2" | 5/16" | 7.7 |
| 4" | 3-1/2" | 3/8" | 9.1 |
| 4" | 3-1/2" | 1/2" | 11.9 |
| 5" | 3" | 1/4" | 6.6 |
| 5" | 3" | 5/16" | 8.2 |
| 5" | 3" | 3/8" | 9.8 |
| 5" | 3" | 1/2" | 12.8 |
| 5" | 3-1/2" | 1/4" | 7 |
| 5" | 3-1/2" | 5/16" | 8.7 |
| 5" | 3-1/2" | 3/8" | 10.4 |
| 5" | 3-1/2" | 1/2" | 13.6 |
| 5" | 3-1/2" | 3/4" | 19.8 |
| 6" | 3-1/2" | 5/16" | 9.8 |
| 6" | 3-1/2" | 3/8" | 11.7 |
| 6" | 3-1/2" | 1/2" | 15.3 |
| 6" | 4" | 5/16" | 10.3 |
| 6" | 4" | 3/8" | 12.3 |
| 6" | 4" | 1/2" | 16.2 |
| 6" | 4" | 5/8" | 20 |
| 6" | 4" | 3/4" | 23.6 |
| 7" | 4" | 3/8" | 13.6 |
| 7" | 4" | 1/2" | 17.9 |
| 8" | 4" | 1/2" | 19.6 |
| 8" | 6" | 1/2" | 23 |
